*Inside size : 6300×3450×2800mm (L*W*H)

*Outside Size  : 7550×3550×3200mm (L*W*H)

*Basement system : Without；

*Ceiling system : 6400×3550×520mm (L×W×H),With powder coated steel plate on 4

sides ; with lights on 2 sides ; Full ceiling filter system.

*Generator Setting Type : Back exhaust air, quadrate steel frame, white coated steel.

*Exhaust air system : Cabinet size 2290×1200×1800 mm(L×W×H);

With1 set 5.5KW air fan ，air capacity is 16000m³/h；

*Seal Type :  Back side set 50mm EPS, other 3 sides with PVC soft curtain.

*Ceiling Installation : Steel rope hanging or steel pole supporting the roof(Option).

*Filtering System : Pre-filter, ceiling filters,fiberglass filter.

*Lighting System : 8pcs*4units*16w LED lighting .

*Control System : Fan switch, electric damper switch. *

*Voltage and Frequency : 380V,3Phase,50HZ . *

Total Power  : 6.012 KW.
